Shower Systems and Enclosures: Types, Glass, and Installation

The shower area is the part of a bathroom where an installation mistake costs the most: a concealed mixer gets built into the wall before the tile goes in, and reworking it after the fact means chiseling the wall open again. A tempered-glass enclosure isn’t just a design choice either — it’s a matter of safety and precise material thickness. When sourcing from China, lock down the mixer’s mount type, valve class, glass thickness, and tray material up front — otherwise the factory will ship the minimum acceptable spec. Here’s what makes up a shower area and what to check before you order.

Concealed or exposed mixer installation

A shower system comes in two fundamentally different mount types, and the choice determines what you need to hand the factory before finishing work starts.

• Concealed installation: the mixer body (a rough-in box) is built into the wall during the rough-in stage, leaving only the handles and spout exposed. The upside is a clean, minimalist look with no visible piping. The downside: reworking it after tiling means tearing out the wall — the recess depth to the finished surface (usually 5-8 cm from the rough wall) has to be handed to the factory exactly, or the handles end up sunk too deep or sticking too far out.
• Exposed (surface-mount) installation: all the fittings sit on the wall surface, with pipework visible or partly covered by a decorative trim. It’s easier to install and service without cutting into walls, and cheaper. It looks less polished, so it suits budget projects and short-term rentals better, where renovation speed matters more than the visual.

Thermostatic or manual mixer

The valve type determines how well the system holds temperature.

• Thermostatic mixer: holds the set temperature to within 0.5 °C and automatically cuts off above 38 °C — critical for kids’ bathrooms and hotel rooms, where a pressure spike elsewhere (a toilet flushing on the floor above, say) shouldn’t turn into a scald. It needs stable line pressure of 1-5 bar.
• Manual mixer: temperature and flow are adjusted by hand with one or two handles, with no automatic scald protection. It costs 2-3x less, but pressure swings in the system can make the water suddenly run cold or dangerously hot. For properties with unstable pressure (a private house on a booster pump, for instance), look at versions with a pressure-balancing cartridge — a middle ground between manual and thermostatic.

Shower columns and panels

A ready-made shower column (panel) is an aluminum or stainless-steel unit combining an overhead rain head, a handheld shower, and sometimes body jets in one module that mounts straight onto the wall with no wall-cutting required.

• Pros: installs in a day, needs no concealed plumbing, and works well for renovations that can’t open up walls — a common pick for refreshing hotel rooms.
• Cons: less flexible design than a separate mixer-plus-handheld setup; if a jet fails, you often have to replace the whole module or wait on a part from the factory.
• What to check: the overhead head’s diameter (200-300 mm for a compact head, 350-400 mm for the “tropical rain” effect), the body material (stainless steel outlasts chrome-plated plastic), and whether the panel itself has built-in thermostatic control.

Tempered glass: thickness and frame type

A shower enclosure is almost always tempered safety glass (per the EN 12150 standard): if it breaks, it shatters into small, blunt fragments rather than sharp shards. Thickness and frame type drive both structural rigidity and price.

• 6 mm — the minimum thickness for framed and semi-framed enclosures, where a perimeter aluminum profile carries the glass’s weight. Cheaper, but you’ll feel a slight play when opening the door.
• 8 mm — the standard for semi-frameless and light frameless doors: a good balance of price and rigidity for most residential projects.
• 10 mm — mandatory for fully frameless enclosures with no top rail: only thick glass holds its geometry without vibrating or sagging on the hinges.

Frame type: framed (glass runs the full perimeter inside an aluminum frame — the cheapest, most rigid option, but visually bulky), semi-frameless (a frame only at the floor and one side — a compromise between price and looks), and frameless (glass hangs only on the lower hinges and a gasket, with no visible metal — the most premium look, but it needs thick glass and precise opening geometry: a factory can no longer compensate for wall deviation beyond 5-8 mm).

It’s also worth locking in a limescale-resistant nano-coating (easy-clean coating) — without one, hard-water streaks show up on clear glass within a month.

Trays: acrylic, engineered stone, or a flush floor drain

• Acrylic tray: lightweight (15-20 kg), affordable, comes in a wide range of shapes, but less resistant to point impacts and can lose its shine over time.
• Engineered-stone (composite) tray: heavier and pricier, but tougher, with a matte, slip-resistant surface — the preferred choice for hotels and high-traffic properties.
• Flush-to-floor drain, no tray: tile is laid on a slope straight onto a waterproofing membrane, so the shower area sits flush with the rest of the floor. It’s the most modern look, but it demands precise slope planning (usually 1.5-2%) and a linear drain set at the rough-in stage — a design error here means water pooling on the floor.

Comparison table

Tray / solution	Weight	Curb height	Price	Where to use
Acrylic tray	15-20 kg	10-15 cm	$	Budget and mid-range projects
Engineered-stone tray	25-40 kg	3-15 cm	$$$	Premium homes, HORECA
Tiled flush-to-floor drain	—	0 cm (flush)	$$-$$$	Modern minimalism, accessible design

What to lock down in the spec when ordering from a factory

• Mixer mount type (concealed/exposed) and the exact recess depth to the finished surface.
• Valve class (thermostatic/manual) and the maximum temperature cutoff.
• Glass thickness (6/8/10 mm) and frame type — sized to the actual opening, not a generic “standard size.”
• Tray material, and the drain slope for a no-tray installation.
• Anti-limescale glass coating and the gasket quality on the hinges.
